Tile Leveling Clips Manufacturer & Wholesale Supplier
Professional PP tile leveling clips. 0.5–4.5mm joint widths. Break-off design. Factory-direct wholesale.
The tile leveling clip is the single-use base in a clip-and-wedge system — 10 break-off models spanning 0.5–4.5mm joints for 3–24mm tiles. Choose the base width from the specified grout joint and choose the model from the tile-body thickness; clips align adjacent edges while mortar cures but do not correct substrate flatness or tile warpage. On a regular 60×60cm floor grid, plan about 11 clips per m².
Guide price: FOB Ningbo at standard MOQ. Raw material costs and selected specifications can change the current quotation.
CE Marked
ISO 9001
TÜV Rheinland
SGS Certified
RoHS Tile Leveling Clips Models — Choose Your Size
Find models that fit your tile and grout joint
Enter the tile-body thickness and required grout-joint width to narrow the catalog models.
10 catalog models available. Add one or both dimensions to narrow the list.
Confirm clip opening, strap geometry, wedge travel and removal method with a physical sample before mixing brands or placing a bulk order.
BM-B01
Dimensions: 37×25×40mm
Tile Thickness: 3–14mm
Spacer Options:
- 1.0mm → 3.4g/pcs
- 1.5mm → 3.43g/pcs
- 2.0mm → 3.5g/pcs
- 3.0mm → 3.6g/pcs
Standard dual-hole clip
Verified model and carton references
BM-B01 through BM-B10 are currently offered models. Exact unit weights are published separately for each model and thickness in the model specification table. The logistics figures below are recorded pack/carton references: standard-size rows were measured on 1.5mm and may differ slightly for 2.0mm, 2.5mm and 3.0mm; explicit 0.5mm and 4.5mm rows use their own records. Do not calculate final bag or carton weight by multiplying unit weight. Source: ZEBRA product and packing records reviewed 2026-10-04; the approved packing list governs the shipment.
| Model / option | Inner pack | Master carton | Reference pack weight | N.W. / G.W. | Carton size | RFQ |
|---|---|---|---|---|---|---|
| BM-B01Non-Breakable Large Solid Base · standard-size reference · measured on 1.5 mm · standard | 100 pcs | 30 packs | 340 g | 9.9 kg / 11 kg | 56×38×35 cm | Add model to RFQ → |
| BM-B02Small Solid Base · standard-size reference · measured on 1.5 mm · standard | 100 pcs | 50 packs | 250 g | 12.5 kg / 13.5 kg | 55×42×41 cm | Add model to RFQ → |
| BM-B03Legacy Round-Hole Base · standard-size reference · measured on 1.5 mm · standard | 100 pcs | 30 packs | 275 g | 8.2 kg / 9.2 kg | 56×38×35 cm | Add model to RFQ → |
| BM-B04Medium Round-Hole Base · standard-size reference · measured on 1.5 mm · standard | 100 pcs | 60 packs | 160 g | 10.5 kg / 11.7 kg | 58×43×43 cm | Add model to RFQ → |
| BM-B05Square-Hole Base · standard-size reference · measured on 1.5 mm · standard | 100 pcs | 30 packs | 270 g | 8.2 kg / 9 kg | 56×38×33 cm | Add model to RFQ → |
| BM-B05Square-Hole Base · 0.5 mm · standard | 100 pcs | 50 packs | 220 g | 11 kg / 12.2 kg | 56.5×42×44 cm | Add model to RFQ → |
| BM-B05Square-Hole Base · 4.5 mm · standard | 100 pcs | 40 packs | 300 g | 12 kg / 13.2 kg | 58×43×43 cm | Add model to RFQ → |
| BM-B06Raised Square-Hole Base · standard-size reference · measured on 1.5 mm · standard | 100 pcs | 40 packs | 280 g | 11.2 kg / 12 kg | 55×42×41 cm | Add model to RFQ → |
| BM-B07Non-Breakable Large Solid Base · standard-size reference · measured on 1.5 mm · standard | 100 pcs | 30 packs | 360 g | 10 kg / 11 kg | 56×38×35 cm | Add model to RFQ → |
| BM-B08Flag Base · standard-size reference · measured on 1.5 mm · printed bag and carton | 100 pcs | 50 packs | 122 g | 6.5 kg / 7.5 kg | 50×38×25 cm | Add model to RFQ → |
| BM-B08Flag Base · standard-size reference · measured on 1.5 mm · plain film and carton | 100 pcs | 50 packs | 122 g | 6.5 kg / 7.5 kg | 47×36×22 cm | Add model to RFQ → |
| BM-B09Double-Post Gate Base · standard-size reference · measured on 1.5 mm · printed bag and carton | 100 pcs | 50 packs | — | 5.8 kg / 6.8 kg | 50×38×25 cm | Add model to RFQ → |
| BM-B09Double-Post Gate Base · standard-size reference · measured on 1.5 mm · plain film and carton | 100 pcs | 50 packs | — | 5.8 kg / 6.8 kg | 47×36×22 cm | Add model to RFQ → |
| BM-B10Ring Base · standard-size reference · measured on 1.5 mm · printed bag and carton | 100 pcs | 50 packs | — | 5 kg / 5.8 kg | 50×38×25 cm | Add model to RFQ → |
| BM-B10Ring Base · standard-size reference · measured on 1.5 mm · plain film and carton | 100 pcs | 50 packs | — | 5 kg / 5.8 kg | 47×36×22 cm | Add model to RFQ → |
Packaging dataset2026-10-04.14 · 2026-10-04
Tile Leveling Clips Technical Specifications
| Model | Dimensions | Tile Thickness | Spacer Options | Weight Range |
|---|---|---|---|---|
| BM-B01 | 37×25×40mm | 3–14mm | 1.0mm, 1.5mm, 2.0mm, 3.0mm | 3.4g – 3.6g |
| BM-B02 | 35.5×22.4×39.3mm | 3–14mm | 1.0mm, 1.5mm, 2.0mm, 3.0mm | 2.2g – 2.5g |
| BM-B03 | 36×25×40mm | 3–14mm | 1.0mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm | 2.4g – 2.73g |
| BM-B04 | 35×25×35mm | 3–14mm | 1.0mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm | 1.5g – 1.96g |
| BM-B05 | 37×25×40mm | 3–14mm | 0.5mm, 1.0mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.5mm | 2.33g – 3g |
| BM-B06 | 36×22.8×49mm | 14–24mm | 1.0mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm | 2.44g – 3.04g |
| BM-B07 | 38×23.7×39.4mm | 3–14mm | 1.0mm, 1.5mm, 2.0mm, 3.0mm | 3.3g – 3.8g |
| BM-B08 | 20×20×30mm | 3–12mm | 1.0mm, 1.5mm | 1.2g |
| BM-B09 | 23.8×16×33mm | 3–14mm | 0.5mm, 0.7mm, 1.0mm, 1.5mm, 2.0mm | 1g – 1.2g |
| BM-B10 | 21×21×43.4mm | 3–10mm | 0.8mm, 1.0mm, 1.5mm, 2.0mm | 0.8g – 1g |
View all model × joint-width unit weights (45 specifications)
| Model | Dimensions | Tile Thickness | Joint Width | Unit Weight |
|---|---|---|---|---|
| BM-B01 | 37×25×40mm | 3–14mm | 1.0mm | 3.4g |
| BM-B01 | 37×25×40mm | 3–14mm | 1.5mm | 3.43g |
| BM-B01 | 37×25×40mm | 3–14mm | 2.0mm | 3.5g |
| BM-B01 | 37×25×40mm | 3–14mm | 3.0mm | 3.6g |
| BM-B02 | 35.5×22.4×39.3mm | 3–14mm | 1.0mm | 2.2g |
| BM-B02 | 35.5×22.4×39.3mm | 3–14mm | 1.5mm | 2.3g |
| BM-B02 | 35.5×22.4×39.3mm | 3–14mm | 2.0mm | 2.4g |
| BM-B02 | 35.5×22.4×39.3mm | 3–14mm | 3.0mm | 2.5g |
| BM-B03 | 36×25×40mm | 3–14mm | 1.0mm | 2.4g |
| BM-B03 | 36×25×40mm | 3–14mm | 1.5mm | 2.5g |
| BM-B03 | 36×25×40mm | 3–14mm | 2.0mm | 2.6g |
| BM-B03 | 36×25×40mm | 3–14mm | 2.5mm | 2.73g |
| BM-B03 | 36×25×40mm | 3–14mm | 3.0mm | 2.6g |
| BM-B04 | 35×25×35mm | 3–14mm | 1.0mm | 1.5g |
| BM-B04 | 35×25×35mm | 3–14mm | 1.5mm | 1.55g |
| BM-B04 | 35×25×35mm | 3–14mm | 2.0mm | 1.68g |
| BM-B04 | 35×25×35mm | 3–14mm | 2.5mm | 1.9g |
| BM-B04 | 35×25×35mm | 3–14mm | 3.0mm | 1.96g |
| BM-B05 | 37×25×40mm | 3–14mm | 0.5mm | 2.33g |
| BM-B05 | 37×25×40mm | 3–14mm | 1.0mm | 2.36g |
| BM-B05 | 37×25×40mm | 3–14mm | 1.5mm | 2.47g |
| BM-B05 | 37×25×40mm | 3–14mm | 2.0mm | 2.6g |
| BM-B05 | 37×25×40mm | 3–14mm | 2.5mm | 2.66g |
| BM-B05 | 37×25×40mm | 3–14mm | 3.0mm | 2.73g |
| BM-B05 | 37×25×40mm | 3–14mm | 4.5mm | 3g |
| BM-B06 | 36×22.8×49mm | 14–24mm | 1.0mm | 2.44g |
| BM-B06 | 36×22.8×49mm | 14–24mm | 1.5mm | 2.65g |
| BM-B06 | 36×22.8×49mm | 14–24mm | 2.0mm | 2.83g |
| BM-B06 | 36×22.8×49mm | 14–24mm | 2.5mm | 2.77g |
| BM-B06 | 36×22.8×49mm | 14–24mm | 3.0mm | 3.04g |
| BM-B07 | 38×23.7×39.4mm | 3–14mm | 1.0mm | 3.5g |
| BM-B07 | 38×23.7×39.4mm | 3–14mm | 1.5mm | 3.3g |
| BM-B07 | 38×23.7×39.4mm | 3–14mm | 2.0mm | 3.5g |
| BM-B07 | 38×23.7×39.4mm | 3–14mm | 3.0mm | 3.8g |
| BM-B08 | 20×20×30mm | 3–12mm | 1.0mm | 1.2g |
| BM-B08 | 20×20×30mm | 3–12mm | 1.5mm | 1.2g |
| BM-B09 | 23.8×16×33mm | 3–14mm | 0.5mm | 1g |
| BM-B09 | 23.8×16×33mm | 3–14mm | 0.7mm | 1g |
| BM-B09 | 23.8×16×33mm | 3–14mm | 1.0mm | 1.1g |
| BM-B09 | 23.8×16×33mm | 3–14mm | 1.5mm | 1.2g |
| BM-B09 | 23.8×16×33mm | 3–14mm | 2.0mm | 1.2g |
| BM-B10 | 21×21×43.4mm | 3–10mm | 0.8mm | 0.8g |
| BM-B10 | 21×21×43.4mm | 3–10mm | 1.0mm | 0.9g |
| BM-B10 | 21×21×43.4mm | 3–10mm | 1.5mm | 1g |
| BM-B10 | 21×21×43.4mm | 3–10mm | 2.0mm | 0.9g |
Tile Leveling Clips for Wholesale & Bulk Orders — Factory-Direct Pricing
As a tile leveling clips manufacturer and wholesale supplier in Wenzhou, China, we supply wholesale buyers with factory-direct pricing. MOQ starts at 500 bags for standard clips — 100 pcs per bag. For bulk orders over 20,000 bags, contact us for volume discounts.
Clip-and-wedge compatibility is model-specific. Before mixing brands, confirm the clip opening, strap geometry, wedge travel and removal method with a physical sample; for a documented fit, pair each ZEBRA clip with its specified ZEBRA wedge. The clip helps align adjacent tile edges while mortar cures, but it does not correct an uneven substrate or warped tile.
1.0mm Tile Leveling Clips
For thin ceramic tiles (3-6mm). Narrow 1.0mm joint for residential wall applications. Standard MOQ 500 bags.
1.5mm Tile Leveling Clips
Most popular SKU for wholesale distributors. Standard ceramic and porcelain floor tiles. Pre-scored for clean break-off. MOQ 500 bags.
2.0mm Tile Leveling Clips
Recommended for large format tiles (60×120cm+). Wider joint accommodates substrate variation. Essential for GCC and European markets. MOQ 500 bags.
3.0mm Tile Leveling Clips
For commercial projects with strict lippage tolerance and natural stone. Common in Middle East and North American specifications. MOQ 500 bags.
ZEBRA TOOLS is a professional tile leveling system manufacturer supplying clips, wedges, pliers and complete leveling systems.
Guide prices are FOB Ningbo at MOQ and subject to raw material cost fluctuations. Contact us for current pricing.
What Tile Leveling Clips Control — and What They Cannot Fix
- The selected grout-joint width
- Adjacent tile-edge alignment during cure
- Repeatable wedge position and tension
- A designed break-off point below the joint
- An uneven or out-of-tolerance substrate
- Warped or bowed tile bodies
- Insufficient mortar coverage or voids
- Wrong cure time or removal direction
OEM Tile Leveling Clips — Private Label, Custom Colors & Packaging
We offer full OEM/ODM customization for wholesale buyers. Match any Pantone color, add your logo to the bag, or develop a custom clip profile with our in-house mold shop. Custom Pantone color MOQ starts at 5,000 bags per color. Production lead time 10–15 days.
Pantone colors MOQ 5,000 bags.Consistent shade batch-to-batch.
Your brand on printed bags, retail boxes, or blister cards. Vector artwork required.
Unique clip geometries. 15–25 days from 3D design to first sample. Quick quote based on your custom mold specifications.
Tile Leveling Clips Applications & Buyers — Contractors, Distributors & Importers
Suitable for: Distributors / Importers / Wholesalers / Private Label Brands
Recommended Accessories
How to Use Tile Leveling Clips — Step-by-Step Guide
Step 1: Apply Thin-Set Mortar
Spread thin-set mortar on the substrate using a notched trowel. Ensure even coverage across the entire tile area. For large-format tiles (60×60cm+), back-butter each tile for maximum adhesion.
Step 2: Insert the Clip Under the Tile
Slide the leveling clip base under the tile edge before setting it down. Position one clip every 20–30cm along each edge. For corners, place clips approximately 5cm from the corner on both sides.
Step 3: Press Tile Firmly Into Place
Press the tile down firmly onto the thin-set bed. The clip strap should protrude through the grout joint. Verify the strap is centered in the joint and not pinched by the tile edge.
Step 4: Insert the Wedge and Tighten
Insert the wedge through the clip opening and push firmly until snug. Use tile leveling pliers to apply controlled pressure — the wedge will pull the clip strap upward, leveling adjacent tiles to the same plane.
Step 5: Follow the Cure and Removal Instructions
Use the mortar manufacturer’s cure guidance and the selected clip system’s removal instructions; there is no universal 24-hour rule. Remove the reusable wedge as directed, then break the clip in the specified direction along the grout joint and clear the joint before grouting.
Frequently Asked Questions
What is the MOQ for wholesale tile leveling clips?
MOQ starts at 500 bags for standard tile leveling clips (100 pcs/bag). Custom colors MOQ is 5,000 bags per color; private label packaging MOQ is 3,000 bags. For larger orders, the exact price tier is stated in the written quote.
Are your tile leveling clips compatible with other brands of wedges?
Compatibility is model-specific. Before mixing brands, check the opening, geometry, working travel and removal method with physical samples.
Which tile leveling clip size should I choose?
Choose two specifications separately: the clip base width must match the required grout joint, while the model tile-capacity range must include the actual tile-body thickness. Standard BM-B01 to BM-B05 and BM-B07 models cover 3–14mm tiles; BM-B06 covers 14–24mm. See the tile leveling clip thickness guide for the complete model table, then sample-test the selected clip and wedge before a bulk order.
How many tile leveling clips do I need per square meter?
For 60×60cm tiles, place 4 clips per tile — about 11 clips per m². For 12×24-inch tiles, that is about 22 clips per m². One MOQ of 500 bags (100 pcs per bag = 50,000 clips) covers roughly 4,500 m² of 60×60 tile, or about 2,250 m² of 12×24 tile before project contingency. Do not apply a universal wastage percentage; set contingency from the placement drawing, cut edges, openings, pattern junctions and documented site loss. For other tile sizes, use our tile clip calculator for a planning estimate.
Can I customize the color of tile leveling clips?
Yes. We offer Pantone color matching for wholesale orders. Custom color MOQ starts at 5,000 bags per color. Standard colors (white, blue, red, yellow, black) are available from stock with no MOQ premium.
What material are the clips made from?
The PP or PP/PE grade depends on the model and approved order specification. Batch documentation can be provided when agreed. Confirm resin grade, break force and temperature requirement against the approved sample.
Do you offer free samples before bulk purchase?
Evaluation samples are available for qualified wholesale buyers. The dispatch date depends on the selected model, sample preparation and delivery address and is confirmed in the sample arrangement. The buyer normally covers courier freight; any later credit must be stated in the quotation.
How long does wholesale delivery take?
Production and dispatch timing are confirmed in the written quotation after the model, quantity, packaging, stock status and destination are known. Freight transit is estimated separately by route and service.
Which tile leveling clips work for 20mm thick tiles?
BM-B06 covers tile-body thicknesses from 14mm to 24mm, including 20mm outdoor and commercial tiles. It is available with 1.0mm, 1.5mm, 2.0mm, 2.5mm and 3.0mm bases; select the base from the required grout joint and confirm the clip-and-wedge fit with a sample. MOQ 500 bags.
