Reusable Tile Leveling System Manufacturer & Wholesale Supplier

Screw-cap system. PP + steel needle. Reusable across multiple projects. Professional grade. Factory-direct wholesale.

Quick Answer
Reusable Tile Leveling System at a Glance

A screw-cap leveling system with a steel threaded post — tighten the cap, pull the tile flat, then release and reuse it for 50+ cycles. Six cap designs cover 1.0–3.0mm joints for professional floors. Wholesale: MOQ 200 bags of 50 pcs, FOB Ningbo $1.30–1.70/bag, bulk production in 15–25 days after sample approval, with OEM colors and private-label packaging.

Guide FOB Price
$1.30–1.70/bag
Standard MOQ
200 bags
Material
PP + steel needle
Models / Options
6 catalog options
CE MarkedCE Marked ISO 9001ISO 9001 TÜV RheinlandTÜV Rheinland SGS CertifiedSGS Certified RoHSRoHS
Model Selection

Reusable Tile Leveling System Models — Choose Your Size

Compare the available catalog models

Select a model to open its dimensions, working range, weight and application notes below.

6

Showing BM-F01. Select another model to compare its specification.

BM-F01 Reusable Tile Leveling System — 5–20mm

BM-F01

Dimensions: Ø36.4×76.3mm

Tile Thickness: 5–20mm

Weight Range: 10.2g

Packing reference

  • 50 pcs/bag · standard Inner pack 50 pcs · Master carton 40 packs · Reference pack weight 530 g · N.W. / G.W. 22 kg / 23.1 kg · Carton size 55×42×37 cm
Add model to RFQ →

Circular cap · base plate 0.9/1.5mm

Technical Specifications

Reusable Tile Leveling System Technical Specifications

ModelDimensionsTile ThicknessSpacer OptionsWeight Range
BM-F01 Ø36.4×76.3mm5–20mm-10.2g
BM-F02 35.6×31×70mm5–20mm-9.1g
BM-F03 Ø35.48×75.4mm5–20mm-10.1g
BM-F04 Ø36×84.3mm5–20mm-13.6g
BM-F05 30×30×72mm5–20mm-10.6g
BM-F06 29.7×29.7×37.5mm5–20mm-8.28g
Wholesale Bulk Ordering

Reusable Tile Leveling System for Wholesale & Bulk Orders — Factory-Direct Pricing

ZEBRA TOOLS makes all 6 Reusable Tile Leveling System models (BM-F01–BM-F06) in Wenzhou, China and sells them wholesale: MOQ 200 bags per model and an FOB Ningbo guide price of $1.30–1.70/bag at MOQ.

MOQ200 bags

Per model; several models can share one order.

Guide FOB price$1.30–1.70/bag

At MOQ, FOB Ningbo.

Volume tiers200 / 800 / 8,000+

Quantity per order; tier prices are quoted on request.

Lead time15–25 days

Bulk production after the sample is approved.

SamplesFree

Buyer pays DHL freight, credited against the first bulk order; kits leave in 3–5 days.

Payment and terms30% / 70%

30% deposit, 70% before shipment. FOB Ningbo by default; CIF or EXW Wenzhou on request.

How an order is built

  1. Choose the model6 models, BM-F01–BM-F06: select one to see its specs and carton.Open the model selector →
  2. Set the quantity per modelEach model is one order line of at least 200 bags; tiers are counted per order.
  3. Add Cross Tile SpacersQuote Cross Tile Spacers in the same order and shipment.Cross Tile Spacers →
Starter order example

200 bags of Reusable Tile Leveling System = $260–$340 FOB Ningbo.

Full terms for every product line are on the tile leveling system wholesale page; resellers can also apply to the tile leveling system distributor program.

⚖️ Guide prices are FOB Ningbo at MOQ and subject to raw material cost fluctuations — contact us for current pricing. (price book updated 2026-11-19)

OEM & Customization

OEM Reusable Tile Leveling System — Private Label, Custom Colors & Packaging

We offer full OEM leveler customization for wholesale buyers. Custom cap colors, branded packaging, and private label systems. Custom color MOQ starts at 5,000 bags, with production lead time of 15–25 days.

Custom Colors

Pantone colors MOQ 5,000 bags. Consistent shade batch-to-batch.

Private Label Packaging

Your brand on printed bags, retail boxes, or blister cards. AI/PDF vector artwork required.

Custom Molds

Quick quote based on your custom mold specifications.

Explore OEM/ODM capabilities
Ready to order this product?
Wholesale pricing and MOQ for your market.
Wholesale Pricing →
Applications

Reusable Tile Leveling System Applications & Buyers — Contractors, Distributors & Importers

✓ Large format porcelain tiles (60×120cm+)
✓ Marble & natural stone (no hammering — zero chipping risk)
✓ Commercial floors requiring precise leveling
✓ Wall tile installations (5–20mm thickness range)
✓ High-end residential projects

Suitable for: Distributors / Importers / Wholesalers / Private Label Brands

How to Use

How to Use Reusable Screw-Cap Tile Leveler — Step-by-Step Guide

1

Step 1: Place Base Under Tile Edge

Slide the steel reinforced base plate under the tile edge before setting into thin-set. The threaded post must extend through the grout joint. Position levelers every 25–35cm for consistent pressure distribution.

2

Step 2: Set Tile and Thread the Cap

Press the tile into the thin-set bed. Screw the cap onto the threaded post by hand — the steel core provides smooth threading without stripping. Rotate until the cap makes contact with both adjacent tiles.

3

Step 3: Tighten to Level

Use a standard screwdriver or drill with hex bit to tighten the cap further. The mechanical advantage of the screw thread provides powerful leveling force with minimal effort. Continue until both tiles are perfectly flush. For stone tiles, use moderate pressure to avoid chipping.

4

Step 4: Remove and Reuse

After the mortar reaches the removal time stated by its manufacturer, unscrew caps counterclockwise. Recover the reusable components, remove residue before it hardens and inspect each part before the next installation.

Frequently Asked Questions

Frequently Asked Questions

What is the MOQ for wholesale reusable tile levelers?

MOQ starts at 200 bags (50 pcs/bag). Custom colors MOQ is 5,000 bags per color; private label packaging MOQ is 3,000 bags. Price tiers: 200 bags, 800 bags and 8,000+ bags — contact us for tier prices. The reusable tile leveler wholesale guide lists seven buying checks.

How many times can the screw-cap levelers be reused?

50+ cycles, factory-confirmed. The steel cap mechanism is the reused part; the PP base plate (0.9 or 1.5mm) stays under the tile and is single-use. Retire any cap with damaged threads.

Are there reusable tile leveling clips?

Yes, as a screw-cap system rather than a break-off clip. On ZEBRA BM-F01–BM-F06 levelers the steel cap mechanism is reused 50+ times, and only the PP base plate (0.9 or 1.5mm) stays under the tile on each job. They cover 5–20mm tile and 1.0–3.0mm joints, pack 50 pcs per bag and start at 200 bags. Break-off clips are single-use by design.

Are screw-cap levelers better than clip-and-wedge systems?

Choose by tile and job: for 5–20mm tile, delicate surfaces and repeat jobs, screw-cap levelers tighten by hand with no hammering and each cap is reused 50+ times. For 3–14mm tile on large floors, clip-and-wedge covers 9 clip models with wedges also reused 50+ times. disposable vs reusable tile leveling.

What tile thickness do your levelers support?

Our reusable levelers support tile thicknesses from 5mm to 20mm, covering standard ceramic, porcelain, and natural stone tiles. The adjustable screw mechanism accommodates thickness variations within this range.

Can I get the levelers in custom colors?

Yes. OEM color and private-label options are available. The applicable MOQ, approved color standard and production schedule are confirmed in the written quotation after the model and packaging scope are fixed.

Which models and tile thickness?

6 models, BM-F01–BM-F06, all for 5–20 mm tile. Base plates: 0.9 / 1.5 mm.

What is it made of?

PP body with a steel pin; 50 pieces per bag; 8.28–13.6 g per piece by model.

Reusable leveler or clip + wedge?

Reusable leveler: $1.30–1.70/bag (50 pieces per bag), MOQ 200 bags; it is used again on the next job. Clip + wedge: clips $0.47–0.85/bag (100 pieces per bag); the clips are consumed on every job.

How long until the goods are ready?

Samples leave the factory in 3–5 days; bulk production takes 15–25 days after sample approval; a custom mold takes 15–25 development days and costs $2,000–8,000.

Do you offer free leveler samples?

Yes. Product samples are free for qualified B2B buyers. The buyer pays DHL courier freight, and that courier charge is credited against the first bulk order.

How are quality issues handled on wholesale levelers?

Report any manufacturing issue with the order number, model and clear photos or video. Reusable caps and consumable bases are reviewed separately against the confirmed sample and order specification.
